2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter

(17 customer reviews)
Sale!

15,08$64,21$

Add to wishlistAdded to wishlistRemoved from wishlist 0
20A ESC 4PCS2205 20A 5045 4PCS2205 30A 5045 4PCS30A ESC 4PCSRS 2205 2300 4PCSRS 2205 CCW 1PCSRS 2205 CW 1PCSRS2205 20A ESC 4PCSRS2205 30A ESC 4PCS
Clear
SKU: 1005001270601236 Categories: ,

FVT LITTLEBEE Little bee BLHeli-s20A ESC:

1: initial tension: 2-4 s lipo
2: NO BEC
3: continue current: 20A, burst current: 25A up to 10S
4: size: 23.5 * 12mm.
5: weight: 4g (include power and signal wire)
6: Support Muted mode, Oneshot125, Oneshot42 and Multshot and DSHOT
7: Main IC: SILABS EFM8BB21F16, MCU run 48MHz
8: MOS: Both low and high side fets are Nfets
9: switching speed is very fast, it has dedicated driver chip
10: BLHeli S Bootloader & Firmware
FVT LITTLEBEE Little bee BLHeli-s 30A ESC:
1: input voltage: 2-6 S Lipo
2: NO BEC
3: continue current: 30A, burst current: 35A up to 10 S.
4: size: 35 * 17mm.
5: weight: 9g (include power and signal wire)
6: Support Muted mode, Oneshot125, Oneshot42 and Multshot and DSHOT
7: Main IC: SILABS EFM8BB21F16, MCU run 48MHz
8: MOS: Both low and high side fets are Nfets
9: switching speed is very fast, it has dedicated driver chip
10: BLHeli S Bootloader & Firmware Package included: 1pcs or 2pcs / 4pcs /6pcs littlebe spring ESC (as your choice)
RS2205 2300kv Motor:
Model: RS2205-2300
Framework: 12N14P
No. of Cells: 3 – 4S
Length:31.7mm
Shaft: M5
KV: 2300
Max Thrust: 1024g
Diameter: 27.9mm
Propeller Suggested: HQ 5045 BN
Weight: 30g
Features:
1. Race Spec Performances
2. High Strength N52 Neodyum Magnets
3. Active Cooling Fins Greatly Reduce Motor Temeratures
4. Low CG, Light Weight Design
5. Japanese Bearing For Performances
6. Enchance Anti Off U Ring For Safety & Stablility
7. Dual Lock CW / CCW Locknuts
2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter

2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter

Specification: 2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter

Origin

CN(Origin)

Material

Metal

Recommend Age

12+y

Tool Supplies

Assembly Category

RC Parts & Accs

Motors

Use

Vehicles & Remote Control Toys

Remote Control Peripherals/Devices

MOTOR

For Vehicle Type

Airplanes

Four-wheel Drive Attributes

Motors

Brushless Motor

RS2205 2300KV

LittleBee 30A BLHeli_S ESC

30A ESC

LittleBee 20A BLHeli_S ESC

20A ESC

6 Months Warranty


This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Reimbursement or replacement will be done against manufacturing defects.


What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

17 reviews for 2300KV Brushless Motor RS2205 With LittleBee for FPV RC Racing Drone Multicopter

4.5 out of 5
13
2
1
0
1
Write a review
Show all Most Helpful Highest Rating Lowest Rating
  1. A***P

    Delivery 3 weeks, visually everything is OK, though propeller curves but this is consumables)

    Helpful(0) Unhelpful(0)You have already voted this
  2. Customer

    Perfercto service very fast

    Helpful(0) Unhelpful(0)You have already voted this
  3. M***a

    Show recommend store yes

    Helpful(0) Unhelpful(0)You have already voted this
  4. D***n

    All is well, that’s just one of the nuts came without faces on a turn-key basis, bald like a knee. The good that was purchased in advance.

    Helpful(0) Unhelpful(0)You have already voted this
  5. T***e

    infinity trouble . soon wiil be broken. had a trouble within 5 fly. how about another buyer?

    Helpful(0) Unhelpful(0)You have already voted this
  6. J***z

    el producto vino con malos acabados. los motores tienen sobrantes de una pasta azul que sirve de pegamento pero que en uno de los.motores frenaba el movimiento. con trabajo consegui retirar el material sobrante pero observe que todos los motores tenian sobrante de ese material que aunque no afectan el movimiento del motor acaban afectando la simetría y funcionamiento del mismo a largo plazo.

    Helpful(0) Unhelpful(0)You have already voted this
  7. M***r

    Ok

    Helpful(0) Unhelpful(0)You have already voted this
  8. F***I

    good store thank you my Friend

    Helpful(0) Unhelpful(0)You have already voted this
  9. V***r

    While on the sandy barhans reached the burning regulator ESC, the motor burned. The store sent exactly what he lost.

    Helpful(0) Unhelpful(0)You have already voted this
  10. Customer

    well arrived

    Helpful(0) Unhelpful(0)You have already voted this
  11. A***i

    good quality but the connector vetween the ESC and the motor are so bad i damged one ESC from the heat soldering iron because the cupper is not connected with the motor wire at all

    Helpful(0) Unhelpful(0)You have already voted this
  12. N***v

    It came very quickly, I made a set of motors earlier, this one is different and noisy in another

    Helpful(0) Unhelpful(0)You have already voted this
  13. M***n

    I loved the product, the store was very fast with shipping.

    Helpful(0) Unhelpful(0)You have already voted this
  14. A***j

    thank you very very very much very faaaaaaaaaaaaast

    Helpful(0) Unhelpful(0)You have already voted this
  15. K***n

    they are very small and work well

    Helpful(0) Unhelpful(0)You have already voted this
  16. C***a

    Arrived all in perfect condition

    Helpful(0) Unhelpful(0)You have already voted this
  17. T***h

    I got it thanks but I didn’t try yet. I hope the best.

    Helpful(0) Unhelpful(0)You have already voted this
